0 - 15m/min PLC Double Layer Roll Forming Machine For Two Roofing Profiles
| Place of Origin | WUXI CHINA |
|---|---|
| Brand Name | LONGBO |
| Certification | CE; ISO9001 |
| Model Number | LB-1000-1220 |
| Minimum Order Quantity | 1 set |
| Price | negotation |
| Packaging Details | water proof package |
| Delivery Time | 90 days |
| Payment Terms | L/C, D/P, T/T |
| Supply Ability | 2 per month |
Product Details
| Rollers Material | GCR15 | Hardness | 55~58 Degree |
|---|---|---|---|
| Chrome Coated | 0.03mm Thickness | Motor Power | 5.5KW;380V;50HZ |
| Working Speed | 10~20m/min | Color | To Be Customized |
| High Light | double deck roll forming machine,metal roofing forming machine |
||
Product Description
0 - 15m/min PLC Control Dual Level Roll Former For Two Roofing Profiles
of Dual Level Roll Former
- Material thickness: 0.3-0.7mm
- Shaft Diameter: 75mm
- Material width: depend on customer’s requirement
- Decoiler Type: manual or automatical type ( depend on customer’s requirement )
- Weight Capacity Of Decoiler: 5 Ton
- Main Motor Power: 7.5 Kw
- Hydraulic Motor Power: 3 Kw
- Forming Station: approx 18 & 18 ( depend on profile drawing )
- Drive Type: Chain Drive
- Electrical Control: PLC Frequency Control System with touch screen
- PLC: PANASONIC Brand
- Encoder: OMRON Brand
- Transducer: PANASONIC Brand
- Machine Weight: about 8.8 Ton
Work Flowing
Decoiler --- Fedding Guide --- Roll Forming --- Cut-to-length --- Run out table
Main Component
| Decoiler /uncoiler | 1 Unit |
| Feeding Guide | 1 Unit |
| Main Roll Forming Machine | 1 Unit |
| Hydraulic Cutting Device | 1 Unit |
| Hydraulic Station | 1 Unit |
| PLC Computer Control | 1 Unit |
| Output Table | 1 Unit |
Application
Metal roof; steel roof; metal roof wall panel; steel roof wall panel; metal roofing sheet; steel roofing sheet; metal roof panel; steel roof panel; roof wall cladding; roof cladding; wall cladding
Our Advantage
- High Quality
- Reliable
- Durable
- Reasonable Price
- Good after Service
- 1 Year Warranty
- More Than 10 Years Experience
Reference Drawing
