Double Layer Corrugated Sheet Roll Forming Machine For Two Different Profiles
| Place of Origin | WUXI CHINA |
|---|---|
| Brand Name | LONGBO |
| Certification | CE; ISO9001 |
| Model Number | LB-400-500-600 |
| Minimum Order Quantity | 1 set |
| Price | negotation |
| Packaging Details | water proof package |
| Delivery Time | 90 days |
| Payment Terms | L/C, D/P, T/T |
| Supply Ability | 2 per month |
Product Details
| Rollers Material | GCR15 OR #45 | Working Speed | 10~20m/min |
|---|---|---|---|
| PLC | Automatic | Hardness | 55~58 Degree |
| Certification | CE | ||
| High Light | double deck roll forming machine,metal roofing forming machine |
||
Product Description
Double Layer Corrugated IBR Roll Forming Machine For Two Different Profiles
Details of Corrugated IBR Roll Forming Machine
- Material thickness: 0.3-0.8mm for IBR & Corrugated Sheets
- Material width: depend on customer’s requirement
- Decoiler Type: manual or automatical type ( depend on customer’s requirement )
- Weight Capacity Of Decoiler: 5 Ton
- Main Motor Power: 7.5 Kw
- Hydraulic Motor Power: 3 Kw
- Forming Station: approx 18 & 18 ( depend on profile drawing )
- Electrical Control: PLC Frequency Control System with touch screen
- PLC: PANASONIC Brand
- Encoder: OMRON Brand
- Transducer: PANASONIC Brand
- Machine Weight: about 8.5 Ton
Work Flowing
Decoiler --- Fedding Guide --- Roll Forming --- Cut-to-length --- Run out table
Main Component
- Decoiler ---------------------------------------------- --1 Unit
- Feeding guide ---------------------------------------- 1 Unit
- main roll forming machine ---------------------------1 Unit
- Hydraulic cutting device ------------------------------1 Unit
- Hydraulic Station ------------------------------------- 1 Unit
- PLC computer control --------------------------------1 Unit
- Output table ------------------------------------------- 1 Unit
Application
Metal roof; steel roof; metal roof wall panel; steel roof wall panel; metal roofing sheet; steel roofing sheet; metal roof panel; steel roof panel; roof wall cladding; roof cladding; wall cladding
Our Advantage
- High Quality
- Reasonable Price
- Good after Service
- 1 Year Warranty
- More Than 10 Years Experience
Reference Drawing
